Bead Roller Forming Dies for the 24″ Motorized Bead Roller – Explanation of EVERY Die – Eastwood

In this video Matt goes over how to use the Bead Roller Forming Dies for the Motorized Bead Roller!

BUY Forming Dies: https://www.eastwood.com/eastwood-mot…

Motorized Bead Roller: https://www.eastwood.com/motorized-be…

This kit includes an additional 10 dies to use with any bead roller with a 3/4″ turned end shaft. THE EASTWOOD MOTORIZED BEAD ROLLER FORMING DIES FEATURE: Create offset flanges, contours, deep channels, and style lines Use with any 3/4″ shaft bead roller Manufactured of CR12 steel with a Rockwell hardness of 35 HRC With these additional dies on your bead roller you can create offset flanges, contours, deep channels, and style lines. This kit also includes a polyurethane lower “skate board” wheel, which can be used with a variety of upper dies. The dies included in this kit are inside and outside offset dies, 3/8 and 1/2 inch tipping dies, round and knife edge tipping dies, 180 degree lower die, lower edge forming die and a lower forming die. All are made of CR12 steel with a Rockwell hardness of 35 HRC.

(1) Polyurethane Lower Wheel (A)

(1) 180 Degree Lower Die (B)

(1) Inside Offset Die (C)

(1) Outside Offset Die (D)

(1) Knife Edge Tipping Die (E)

(1) Lower Edge Forming Die (F)

(1) 3/8” Tipping Die (G)

(1) 1/2” Tipping Die (H)

(1) Round Tipping Die (I)

(1) Lower Forming Die (J)

(2) 1.375” O.D. x 1.025” I.D. Shaft Adapter Sleeves (K)

(10) M8-1 x 10mm Set Screws

• Material = CR12

• Hardness = 30-40 HRC

• Will fit Bead Rollers with 3/4” shafts and 2-3/4” shaft spacing For more information on Eastwood products visit www.eastwood.com or stay connected with the team via:
